Kenna Universal™ • B966 • 3 x D • Straight Shank
Solid Carbide Drill for Universal Applications
Material Number100004295
Contact our sales team to discover all of your pricing options
Features and benefits
- A four-margin land design provides hole straightness and roundness, even when drilling cross holes.
- The low thrust drill point design has excellent centering capabilities, ideal for less stable machining conditions (allowing the drill to work well on a variety of machines).
- Easy to recondition, delivering extended tool life.
- MQL-ready! All shanks fulfil the DIN 6535 and 69090-03 requirements for minimum quantity lubrication.
Drilling
Drilling: Inclined Exit
Shank - Cylindrical Plain ≤h6
Helix Angle: 30°
DIN number 6537
DIN number 6535
Flood Coolant: Drilling
Tool Dimensions: 2flute/4margin/no cool
Drilling - No Coolant
Drilling: Stacked Plates
Drilling: Cross-Hole Drilling
